BA-DB44
Digital Audio Processor
4 × 4 Analog • Dante 4 × 4 • USB-C • PoE
The BA-DB44 is a compact digital audio processor with 4 analog inputs and 4 analog outputs, 4 × 4 Dante network channels and a USB-C sound card. It pairs high-performance A/D and D/A converters with a 32-bit floating-point DSP at 24-bit / 48 kHz for high-quality sound, full matrix mixing and easy-to-use control software. Powered by PoE or DC 12 V, it suits meeting rooms, video conferencing, places of worship, conference centres and public sound reinforcement systems.
- 32-bit Float DSP
- 4 In / 4 Out Analog
- Dante 4 × 4
- AFC / AEC / ANS Auto Mixer
- USB-C Sound Card
- PoE or DC 12 V
Key features
- Compact digital audio processor with 4 analog inputs and 4 analog outputs.
- High-performance 32-bit floating-point DSP with all-digital processing.
- High-performance A/D and D/A converters, 24-bit / 48 kHz sampling.
- Dante network audio: 4 inputs and 4 outputs.
- Built-in AFC (feedback cancellation), AEC (echo cancellation), ANS (noise suppression) and automatic mixing.
- Comprehensive matrix mixing.
- Input channel processing: preamp, expander, compressor, auto gain, 5-band parametric EQ and ducker.
- Output channel processing: delay, crossover, limiter, 31-band graphic EQ.
- Per-channel phase and mute switches, plus 48 V phantom power on inputs.
- USB-C sound card for playback and recording.
- PoE powered (802.3af/at) or DC 12 V.
- RS232, RS485 and Ethernet control, with real-time management of one or many devices.
- 8 scene presets, with backup to external storage; all software built into the device, so no CD is needed.
Specifications
| Model | BA-DB44 |
|---|---|
| Analog Inputs / Outputs | 4 balanced/line inputs, 4 balanced/line outputs |
| Dante Channels | 4 inputs, 4 outputs |
| USB-C Sound Card | 1 |
| RS232 / RS485 Interfaces | 1 / 1 |
| RJ45 Interfaces | 2 (Dante & PoE, primary / secondary) |
| Sample Rate / Bit Depth | 48 kHz / 24-bit |
| Phantom Power | 48 V |
| Frequency Response | 20 Hz – 20 kHz, ±0.15 dB |
| THD+N | ≤ 0.003% @ 1 kHz, 4 dBu |
| A/D Dynamic Range (A-wtd) | 120 dB |
| D/A Dynamic Range (A-wtd) | 114 dB |
| Input Impedance (Balanced) | 20 kΩ |
| Output Impedance (Balanced) | 100 Ω |
| Channel Isolation | 100 dB @ 1 kHz, 4 dBu |
| S/N Ratio | 107 dB |
| Max. Input / Output Level | 18 dBu / 18 dBu |
| Background Noise | −89 dBu |
| Power Supply | DC 12 V or PoE (802.3af/at) |
| Power Consumption | < 15 W |
| Operating Temperature | −10 – 40 °C |
| Operating Humidity | 10% – 90%, non-condensing |
| Dimensions (W × D × H) | 216 × 190.5 × 44 mm |
| Net Weight | 0.8 kg |
Tender specificationArchitect & engineer text, ready to paste into your spec
The digital audio processor shall be a compact half-rack unit with a 32-bit floating-point DSP and 24-bit / 48 kHz A/D and D/A converters. It shall provide 4 balanced analog inputs, 4 balanced analog outputs, 4 × 4 Dante network channels and a USB-C sound card, with 48 V phantom power. Processing shall include matrix mixing, automatic mixing, AFC, AEC and ANS. Each input shall have an expander, compressor, auto gain, ducker and 5-band parametric EQ, and each output shall have delay, crossover, limiter and 31-band graphic EQ. Frequency response shall be 20 Hz – 20 kHz (±0.15 dB), with THD+N ≤ 0.003% and S/N ratio of 107 dB. Control shall be via Ethernet, RS232 and RS485, with 8 scene presets. It shall be powered by PoE (802.3af/at) or DC 12 V, consume less than 15 W, measure 216 × 190.5 × 44 mm and weigh 0.8 kg.
