BA-88-DAP
Digital Audio Processor
8 × 8 Analog • Dante 4 × 4 • 32-bit DSP • 24-bit / 48 kHz
The BA-88-DAP digital audio processor combines a high-performance 32-bit floating-point DSP with 24-bit / 48 kHz A/D and D/A conversion and an 8-stage preamplifier circuit. It has built-in feedback cancellation, echo cancellation, noise suppression and automatic mixing, plus full matrix mixing, scene presets and easy-to-use control software. It suits theatres, concert halls, video conferencing, stadiums, places of worship, conference centres, theme parks and public sound reinforcement systems.
- 32-bit Float DSP
- 8 In / 8 Out Analog
- Dante 4 × 4
- AFC / AEC / ANS Auto Mixer
- Scene Presets
- Web Control RS232 / 485 / GPIO
Key features
- High-performance 32-bit floating-point DSP with all-digital processing.
- High-performance A/D and D/A converters, 24-bit / 48 kHz sampling.
- 8 analog inputs and 8 analog outputs with very low distortion and ultra-low noise.
- Dante network audio: 4 inputs and 4 outputs.
- Built-in AFC (feedback cancellation), AEC (echo cancellation), ANS (noise suppression) and automatic mixing.
- Comprehensive matrix mixing.
- Input channel processing: preamp, expander, compressor, auto gain, 5-band parametric EQ.
- Output channel processing: delay, crossover, limiter, 31-band graphic EQ.
- Per-channel phase and mute switches, plus 48 V phantom power on inputs.
- Test signal generator: sine wave, pink noise and white noise.
- Camera tracking with VISCA, PELCO-D and PELCO-P protocols and custom commands.
- Built-in web control for Windows, macOS, Linux, Android and iOS.
- RS232, RS485, Ethernet and 4 programmable GPIO ports (3.3–24 V).
- USB music playback and recording.
- Scene presets with backup to external storage, memory retained on power failure, and one-key reset.
Specifications
| Model | BA-88-DAP |
|---|---|
| Analog Inputs / Outputs | 8 / 8 |
| Dante Inputs / Outputs | 4 / 4 |
| RS485 Serial Interfaces | 1 |
| GPIO Interfaces | 4, freely configurable as inputs or outputs |
| RJ45 Interfaces | 2 |
| Sample Rate / Bit Depth | 48 kHz / 24-bit |
| Preamp Gain | 42 dB |
| Phantom Power | 48 V |
| Frequency Response | 20 Hz – 20 kHz, ±0.2 dB |
| THD+N | ≤ 0.003% @ 1 kHz, 4 dBu |
| A/D Dynamic Range (A-wtd) | 120 dB |
| D/A Dynamic Range (A-wtd) | 114 dB |
| Input Impedance (Balanced) | 20 kΩ |
| Output Impedance (Balanced) | 100 Ω |
| EIN (A-wtd) | ≤ −125 dBu |
| Channel Isolation | 100 dB @ 1 kHz, 4 dBu |
| Common Mode Rejection | 70 dB @ 50 Hz |
| S/N Ratio | 108 dB |
| Max. Input / Output Level | 18 dBu / 18 dBu |
| Background Noise | −90 dBu |
| Power Supply | DC 12 V / 2 A |
| Power Consumption | < 15 W |
| Operating Temperature | 0 – 40 °C |
| Operating Humidity | 10% – 90%, non-condensing |
| Dimensions (W × D × H) | 482 × 206 × 44 mm |
| Net / Package Weight | 2.1 kg / 2.5 kg |
| Package Size | 590 × 430 × 110 mm |
Product details
Tender specificationArchitect & engineer text, ready to paste into your spec
The digital audio processor shall be a 19″ 1U unit with a 32-bit floating-point DSP and 24-bit / 48 kHz A/D and D/A converters. It shall provide 8 analog inputs, 8 analog outputs and 4 × 4 Dante network channels, with 42 dB preamp gain and 48 V phantom power. Processing shall include matrix mixing, automatic mixing, AFC, AEC and ANS. Each input shall have an expander, compressor, auto gain and 5-band parametric EQ, and each output shall have delay, crossover, limiter and 31- band graphic EQ. Frequency response shall be 20 Hz – 20 kHz (±0.2 dB), with THD+N ≤ 0.003% and S/N ratio of 108 dB. Control shall be via built-in web interface, Ethernet, RS232, RS485 and 4 programmable GPIO ports, with camera tracking (VISCA / PELCO-D / PELCO-P) and USB playback and recording. It shall operate from DC 12 V / 2 A, consume less than 15 W, measure 482 × 206 × 44 mm and weigh 2.1 kg.
